730nm 1200mW 섬유 결합 레이저 Lab 반도체 레이저 CW and Modulation
This product is for multimode fiber coupling of semiconductor laser,the stability of the output power of the fiber is good and the spot pattern can be improved to a great extent.The collimated beam can meet the high requirement of the beam.
Our company produces single wavelength, polarization maintaining and multimode fiber coupled lasers at various wavelengths, as well as fiber optic coupled lasers with fiber coupled lasers.Please contact us.
Notes:
This is a custom product. If you need other output powe or have special requirements, please contact us.
리드 타임: 2~4 weeks! 맞춤형 제품 가능!
[특징]
1.High power stability(<3%)
2.Multimode fiber coupled,fiber output.
[명세서]
파장:730nm±5nm
출력 파워:1200mW (@ Fiber output side, and 0~max power adjustable)
작동 온도: 0°C-40°C
보관 온도: -40°C-85°C
조정: 0~10KHz TTL
| Parameter |
Work condition |
Symbol |
Min. |
Typical Value |
Max. |
Unit |
| Output Power |
@PO |
PO |
|
|
1200 |
mW |
| Power Stability |
2hrs |
Ps |
|
|
3 |
% |
| Central Wavelength |
@PO |
λc |
|
730 |
|
nm |
| Spectral linewidth |
@PO |
FWHM |
|
2 |
|
nm |
| Fiber core diameter |
|
200um/NA=0.22(Customized) |
| Fiber Length |
|
|
|
100 |
|
cm |
| Fiber Type |
MM Fiber |
| Fiber interface |
|
|
FC/ST/SMA905 |
|
| Warming Time |
@PO |
Tw |
|
|
5 |
min |
| Noise |
RMS(10Hz-100MHz) |
N |
|
1 |
|
% |
| Service Life |
@PO |
MTBF |
10000 |
|
|
Hrs |
