라만 레이저 532nm 200mW 0.1nm Narrow Spectrum Width 섬유 결합 레이저
532nm Raman laser has the characteristics of stable spectrum and small line width.It's Very suitable for Raman and sensing applications.This kind of laser is an optical coupling of 532nm Raman laser,fiber output, in use can be more convenient for the laser spectrometer and integration.
Notes:
This is a custom product, if you need other output power, or have special requirements, please contact us.
리드 타임:
532nm 200mw Raman laser: ~4 weeks
[특징]
1.Spectral stability(<3%)
2.Small line width(0.1nm)
[Applications]
1.Raman spectrum
2.Sensing
[명세서]
파장:532nm
출력 파워:200mW (@ Fiber output side, and 0~max power adjustable)
Fiber Connector:FC/PC or SMA-905 (choose)
섬유 유형:MM Fiber
섬유 길이: 1 meters
Fiber Diameter: 100um
Output Stability (RMS):<5% over 2 hours
조정: 0~10KHz TTL
작동 온도: 0°C-45°C
보관 온도: -40°C-85°C
Warming Time: <5 minutes
Service Life: >5000 hours
Parameter |
Work condition |
Symbol |
Min. |
Typical Value |
Max. |
Unit |
Output Power |
APC |
PO |
|
|
200 |
mW |
Optical Power Stability |
2hrs |
Ps |
|
3 |
5 |
% |
Line Width |
FWHM |
PO |
|
|
<0.1 |
nm |
Spectral Stability |
λs |
PO |
|
|
<0.1 |
nm |
Central Wavelength |
@PO |
λc |
531.5 |
532 |
532.5 |
nm |
Service Life |
@PO |
MTBF |
5000 |
|
|
Hrs |
