785nm 350mW 섬유 결합 레이저 0.2nm Narrow Linewidth 라만 레이저 IR 레이저 소스

785nm 350mW 섬유 결합 레이저 0.2nm Narrow Linewidth 라만 레이저 IR 레이저 소스

The 785nm narrow-linewidth Raman laser produced by our company has narrow spectral line width and good spectral stability, and it has a wide range of applications in Raman analysis. Provides free optical path and fiber-coupled two kinds of production solutions, which can be matched with Raman probes and corresponding accessories, to fully solve the customer's need to build a hardware part of the Raman spectrometer.
The Raman laser has good spectral stability, and the center wavelength remains basically constant under long-term working conditions; the spectral line width is narrow, and it has a very good Raman effect when used as a Raman light source, and is very suitable for pulling. Mann Spectral and Sensing applications.

Notes:
This is a custom product,  if you need other output power, or have special requirements, please contact us.

[Lead Time]
785nm 350mW 라만 레이저: 3~4 weeks

[명세서]
파장: 785nm±5nm
출력 파워: 350mW (@ Fiber output side, and 0~max power adjustable)
Fiber interface: FC/PC or SMA-905(choose)
Fiber diameter:100um
섬유 유형: Multi-mode Fiber
Output stability (rms): <3% over 2 hours
조정: 0~10KHz TTL
작동 온도: 10℃-35℃
보관 온도:  -40°C-85°C
Warm-up Time (minutes): <5
Expected Lifetime (hours): >5000
Warranty Time: 1 Year
