795nm 30mW IR 반도체 레이저 단일 모드 섬유 결합 레이저 Infrared 레이저 소스

795nm 30mW IR 반도체 레이저 단일 모드 섬유 결합 레이저 Infrared 레이저 소스

The laser is a single-mode fiber coupling of the 795nm semiconductor laser. The coupled fiber has good output power stability, and the spot mode is TEM00 mode. The beam quality is very good, which can meet the requirements of high beam quality requirements.

[특징]
Good fiber laser output power stability.
The beam quality is very good.
Spot mode is TEM00 mode

[Specification]
상품명: 795nm fiber coupled laser
리드 타임: 1~3 weeks, 맞춤형 제품 가능!
파장: 795nm±5nm
출력 파워: 30mW (@ Fiber output side, and 0~max power adjustable)
Spot Mode: TEM00
Fiber Connector: FC/PC or SMA-905
섬유 유형: Single mode fiber
Output Stability: <3% over 2 hours
작동 온도: 0℃~40℃
조정: 0~10KHz TTL
Warm-up Time: <5 mintues
Service Life: >5000 hours
