1550nm 15W 고출력 레이저 단일 모드 파이버 레이저 소스

New Pirce 최신 가격 (Click Here 여 기 를 클릭 하 십시오. )

Please Choose:



Add to Cart:


1550nm 15W 고출력 레이저 단일 모드 파이버 레이저 소스

The 1550nm band single-wavelength laser light source (high power) uses DFB semiconductor laser chip, with high-power gain optical path module to achieve single-mode fiber high-power output, professionally designed drive circuit and TEC control to ensure safe and stable laser operation.

[특징]
단일 모드 fiber output
Multiple spectra optional

[Applications]
Fiber optic sensing
Fiber laser
Laser radar

[Specification]

Parameter Unit Typical Value Remarks
Wavelength nm 1550nm±1nm 1540~1565nm customizable
Spectral Linewidth nm <0.1 Customizable
Sideband Suppression Ratio dB >50
Output Power W 15
dBm 41
Short-term Stability (15 minutes) dB ≤ ±0.02
Long-term Stability (8 hours) dB ≤ ±0.05
Pigtail Type   SMF-28e single mode PM1550 PM fiber customizable
Pigtail Connector Type   FC/APC



Electrical and Environmental Parameters

Desktop Type

Control Method

Button

Communication Interface

DB9 Female
(Default not include)

Power Supply

100~240V AC, <150W

Size

260(W)×320(D)×120(H)mm

Operating Temperature Range

-5~+55°C

Operating Humidity Range

0~70%




1550nm sm Fiber laser

1550nm sm Fiber laser
