1610nm 5mW SM Fiber SLD 광대역 광원 Module Type
The SLD broadband light source adopts semiconductor super-radiation diode technology to output a broadband spectrum and at the same time has a higher output power. The working wavelength can be selected from O, S, C, L and other bands, which is suitable for applications such as optical fiber sensing. Can provide communication interface and host computer software to facilitate the monitoring of the state of the light source.
[특징]
Ultra-wide spectrum.
Low spectral ripple.
Flat spectrum.
[Applications]
Fiber optic sensing
Medical imaging
Optical fiber device testing
[Speicfictaion]
| Parameter |
Unit |
Typical Value |
Remarks |
|
Center Wavelength
|
nm
|
1610
|
850/1310/1400/1450/1470/1500/1550/1610/1650
Customizable
|
|
Output Power
|
mW
|
5
|
5/10mW customizable
|
|
Spectral Power Density
|
dBm/nm
|
≥-25
|
|
|
Spectral Ripple
|
dB
|
<0.2
|
|
|
Short-term Stability(15Minutes)
|
dB
|
≤ ±0.02
|
|
|
Long-term Stability(8Hours)
|
dB
|
≤ ±0.05
|
|
|
Degree of Polarization DOP
|
dB
|
≤ 0.2
|
|
|
Pigtail Fiber Type
|
-
|
SMF-28e Singlemode fiber
|
|
|
Pigtail Connector
|
-
|
FC/APC
|
|
|
Electrical and environmental parameters
|
Desktop Type
|
Module Type
(Current Product)
|
|
Control Method
|
Button
|
RS232 Serial communication
|
|
Communication Interface
|
DB9 Female
(Default not include)
|
DB9 Female
|
|
Power Supply
|
100~240V AC, <30W
|
5V DC, <15W
|
|
Size
|
260(W)×280(D)×120(H)mm
|
125(W)×150(D)×20(H)mm
|
|
Operating Temperature Range
|
-5~+55°C
|
|
Operating Humidity Range
|
0~70%
|
