1053nm DPSS 레이저 100mW~500mW 출력전원 조정가능

Starting at: $2,200.00

Please Choose:



Add to Cart:


1053nm DPSS 레이저 100mW~500mW 출력전원 조정가능
1053nm dpss laser 100mw~500mw output power adjustable


[[명세서]]
파장: 1053nm
출력: 100mw/200mw/500mw선택
Working Mode: CW
Transverse: TEM00
Sepctral 선폭: <0.1nm
양극화: Line polarization
Polarizatino Ratio: >8:1
Beam Quality(M2 factor): <1.5
Beam Divergence(full angle,mrad): 1.5±0.2
Beam diameter at Dperture: 2.5±0.2mm
Beam Roundness: >90%
Power stability(RMS): <5%@4hours
애퍼처 위치: 50mm
Dimensions of Laser Head: 205mm L x 60mm W + 60mm H
Integrated Driver Model 차원: 159mm + 144mm + 83mm
External 변조: 5V TTL / 5V Analogue
Modulation Repetition: 30KHz TTL / 10KHz Analoggue
Cooling System: TEC
예열 시간: <15 minutes
Operation Temperature: 18℃ ~ 30℃
예상 수명: > 10,000 hours
Warranty Time: 1 Year
