ASE broadband light source 1528nm~1563nm C-Band 10mW~100mW fiber laser Advanced Desktop type
Gain flattened fiber ASE broadband light source is based on ordinary broadband light source and added the gain flattening technologies, nd optimize the structure of the light source, the output spectral flatness of <2dB, output power and high. Suitable for optical fiber sensing applications.
[명세서]
| Parameter |
Unit |
Typical value |
Remarks |
| Working wavelength |
nm |
1528～1563 |
C-Band |
| Output Power |
mW |
10mW~100mW |
Choose |
| 조정 가능한 출력 전력 |
|
Adjustment range
10%~100% |
Choose
1. Not Include(Fixed output power)
2.Include(Adjustable output power) |
| Output isolation |
dBm |
>35 |
|
| Spectral flatness |
dB |
1.5 (Type), 2(Max) |
|
| Short-term stability (15 minutes) |
dB |
≤ ±0.02 |
|
| Long-term stability (8 hours) |
dB |
≤ ±0.05 |
|
| Fiber type |
|
단일 모드 Fiber SMF-28e |
|
| Fiber Optic Output Type |
|
FC/APC (Default) |
Accept custom |
| Operating temperature |
°C |
-20°C ～ 65°C |
|
| Storage temperature |
°C |
-40°C ～ 85°C |
|
| Size |
|
LCD Desktop type
260(W)×280(D)×120(H) |
|
| Power supply |
|
AC 110V~220V |
|
| Control method |
|
Button |
|
| Communication interface |
|
DB9 Female(RS232) |
Default not include, Only for output power adjustable model.
Add software control functions, please contact us. |
