TTL modulation 808nm 5mw~250mw IR laser Module 16*60mm

Product 69/72

 Previous
 Return to the Product List
 Next

New Pirce 최신 가격 (Click Here 여 기 를 클릭 하 십시오. )

Please Choose:







Add to Cart:


TTL modulation 808nm 5mw~250mw IR laser Module 16*60mm

SPECIFICATIONS:
이름: TTL modulation 808 IR laser Module
출력 파장: 808nm
출력 파워: 5mW~250mw(Choice)
레이저 모양: Rectangle
Laser type: Invisible laser, IR laser
Outside Color: Black
Beam Divergence: 0.1mrad ~ 0.6mrad adjustable
Optical Systems: Optical Coated Glass
Spot Description: 1m department width => spot diameter Φ0.5mm
조정: TTL modulation
Modulation frequency: 1Hz-1MHz
작동 전압: DC 3V ~ 5V
Laser Class: IIIB
작동 온도: -10℃~70℃
보관 온도: -40℃~80℃
크기: Φ16mm x 60 mm
Continuous working time: > 12 hours(Good heat dissipation)
보증:6 Months Factory warranty


TTL modulation Description:
1 The red and yellow lines shorted, the module will be lit, in a continuous mode of operation;
2 To modulate the signal line negative black wire, positive connected to the yellow line, red line vacant, modulation module in working condition.
3 Signal input modulation frequency must be within the range 500KHZ;


Package includes:
1* TTL IR laser module
