532nm 8W 녹색 레이저 모듈/Automatic refrigeration/고성능 녹색 DPSS 레이저

New Pirce 최신 가격 (Click Here 여 기 를 클릭 하 십시오. )

Add to Cart:


T532D8WD green laser show:
The imported laser diode pump source, T532D8WD DPSS green laser are made of high quality high quality nonlinear crystal and collimating lens, with temperature control of high performance driving power, the active temperature control, with high efficiency, good stability, good beam quality, low noise, strong anti-jamming, good consistency, compact structure, miniaturization, long life and so on.
Products are widely used in medicine, laser show, isotope separation, ultra-high density optical storage, precision materials processing, lithography, spectrum analysis etc..

SPECIFICATIONS:

Model: T532D8WD
파장: 532nm
작동 모드:  CW
Output power:  >8W
Spatial mode:   Near TEM00
Longitudinal mode:  Multi
Spectral linewidth:  0.1nm
편광:  Linear vertical
Polarization ratio:  >100:1
Beam quality:   M2<1.8
Beam divergence full angle:   1.8mrad

Beam diameter at aperture:  3mm
Beam ellipticity:   1±0.1
Beam pointing stability:  0.03mrad
전원 안정성:       ±5% over 8 hrs rms
Optical axis height:   78mm
Size of laser head:    LxWxH=1805x150x125mm
Size of power supply:  LxWxH=238x146x102mm
Cabel-laser head:      1.0, 1.5m
Weight of laser head:  2.6kg
Weight of power supply:  2.3kg
TTL 조정: 0V-no lasing, 5V-lasing
Frequency of TTL:  1kHz-30kHz
Efficiency of TTL:  40%-60%
Analogue 조정:  0-5V
Frequency of analogue:  1kHz-10kHz
Cooling mode:      TEC
Operating votage:     90-260VAC
Maximum power consumption:  50W
Warm-up time:   15 mintues
Operating temperature:  0-35℃
Storage temperature:   -20-60℃(<90% relative humidity, non-condensing)
Expected life time:  10,000 hours
Warranty time:  1 year

메모:
This size is for reference only. The size of the latest model may changed.
If there is any requirement for size, please contact us get latest size.
