Diameter 40mm 650nm 100mW 빨간색 Parallel Light Laser Support customization

Diameter 40mm 650nm 100mW 빨간색  Parallel Light Laser Support customization

This laser has the characteristics of small beam divergence angle, high parallelism, full circle spot and uniform brightness.

Features:
1. New German import tube + optical coating glass lens group.
2. Light passing rate, light energy loss is small, can be open 24 hours a day.
3. Intelligent drive board with imported IC can supply power in a wide range of 2.8-5.2V.
4. The internal heat filled with silica gel and AB glue can make heat dissipation and shockproof.
5. The shell is made of aviation aluminum insulation paint.
6. High temperature resistant and corrosion resistant DC plug wire.

SPECIFICATIONS:
파장:  650nm (Customizable: 635nm/660nm/808nm/980nm)
Output power:  100mW（Customizable: 0.5-1500mw）
Laser shape:  Round spot (The spot size is adjustable)
작동 전압:  DC 2.8-5.2V (Customizable)
Operating current:  ≤500mA
크기:  45.2*24*168mm
Beam divergence angle:  0.02mrad
Parallel beam diameter:  40mm (Customizable: 20mm/30mm/35mm)
Optical lens:  Optical coating glass lenses set imported from Germany
Adjustable minimum spot (1-20m):  2mm
                                          (20-50m):  3mm
                                          (50-80m):  4mm
                                          (80-100m):  5mm
