지난 2021년에는 시장에서 1064nm 단일 모드 파이버 레이저에 대한 수요가 많았습니다. 대부분의 고객은 과학 연구 분야에서 레이저를 적용하고 있으며, 레이저의 전력 안정성에 대한 요구 사항이 상대적으로 높으며 고객은 종종 8 시간 이상의 전력 안정성 테스트 보고서를 제공하도록 요청합니다.
아래는 1064nm 100mW SM 파이버 레이저의 출력을 43mW로 조정했을 때 수행한 26시간 안정성 테스트 데이터입니다.
기타 지침:
이 테스트는 간섭 요인을 최대한 제거했습니다.
- 레이저, 광섬유 및 파워 미터는 절대적으로 안정적이고 만질 수 없어야 하며 사람들을 테스트 영역에서 멀리 유지하고 레이저의 어떤 부분도 만지지 마십시오.
- 광섬유는 광전력계에 직접 연결되며 어댑터는 사용되지 않습니다.
- 레이저 근처의 자기장 간섭을 제거합니다.
1064nm SM FC 레이저의 기본 매개변수:
전원 안정성: ±0.5759%
전력 변동: 16.44-16.39 = 0.05dBm
전원 안정성: ±0.705%
최소: 16.375dBm
최대: 16.437dBm
전력 변동: 0.062dBm
2021/12/17 12:11:36.916 1.6399E+1 dBm
2021/12/17 12:11:35.825 1.6398E+1 dBm
2021/12/17 12:11:30.680 1.6397E+1 dBm
2021/12/17 12:11:29.589 1.6397E+1 dBm
2021/12/17 12:11:26.169 1.6399E+1 dBm
2021/12/17 12:11:21.469 1.6396E+1 dBm
2021/12/17 12:11:20.415 1.6395E+1 dBm
2021/12/17 12:11:15.881 1.6401E+1 dBm
2021/12/17 12:11:14.805 1.6400E+1 dBm
2021/12/17 12:11:11.205 1.6398E+1 dBm
2021/12/17 12:11:06.880 1.6395E+1 dBm
2021/12/17 12:11:05.777 1.6395E+1 dBm
2021/12/17 12:11:01.517 1.6395E+1 dBm
2021/12/17 12:11:00.454 1.6402E+1 dBm
2021/12/17 12:10:56.381 1.6397E+1 dBm
2021/12/17 12:10:55.308 1.6398E+1 dBm
2021/12/17 12:10:51.133 1.6398E+1 dBm
2021/12/17 12:10:50.016 1.6398E+1 dBm
2021/12/17 12:10:45.981 1.6396E+1 dBm
2021/12/17 12:10:44.900 1.6398E+1 dBm
2021/12/17 12:10:40.081 1.6402E+1 dBm
2021/12/17 12:10:38.974 1.6401E+1 dBm
2021/12/17 12:10:35.560 1.6401E+1 dBm
2021/12/17 12:10:32.018 1.6401E+1 dBm
2021/12/17 12:10:27.726 1.6401E+1 dBm
2021/12/17 12:10:26.668 1.6400E+1 dBm
2021/12/17 12:10:22.382 1.6398E+1 dBm
2021/12/17 12:10:21.304 1.6398E+1 dBm
2021/12/17 12:10:17.031 1.6397E+1 dBm
2021/12/17 12:10:15.948 1.6400E+1 dBm
2021/12/17 12:10:11.781 1.6401E+1 dBm
2021/12/17 12:10:10.670 1.6399E+1 dBm
2021/12/17 12:10:06.133 1.6399E+1 dBm
2021/12/17 12:10:05.066 1.6401E+1 dBm
2021/12/17 12:09:59.719 1.6399E+1 dBm
2021/12/17 12:09:58.636 1.6400E+1 dBm
2021/12/17 12:09:54.125 1.6400E+1 dBm
2021/12/17 12:09:53.069 1.6405E+1 dBm
2021/12/17 12:09:48.731 1.6403E+1 dBm
2021/12/17 12:09:47.666 1.6401E+1 dBm
2021/12/17 12:09:43.181 1.6393E+1 dBm
2021/12/17 12:09:42.080 1.6403E+1 dBm
2021/12/17 12:09:37.682 1.6401E+1 dBm
2021/12/17 12:09:36.591 1.6403E+1 dBm
2021/12/17 12:09:32.184 1.6400E+1 dBm
2021/12/17 12:09:31.076 1.6400E+1 dBm
2021/12/17 12:09:26.482 1.6401E+1 dBm
2021/12/17 12:09:25.400 1.6401E+1 dBm
2021/12/17 12:09:21.224 1.6401E+1 dBm
2021/12/17 12:09:20.170 1.6400E+1 dBm
… …
2021/12/16 9:57:13.370 1.6418E+1 dBm
2021/12/16 9:57:12.317 1.6419E+1 dBm
2021/12/16 9:57:11.268 1.6415E+1 dBm
2021/12/16 9:57:10.218 1.6413E+1 dBm
2021/12/16 9:57:09.170 1.6413E+1 dBm
2021/12/16 9:57:08.118 1.6411E+1 dBm
2021/12/16 9:57:07.069 1.6415E+1 dBm
2021/12/16 9:57:06.018 1.6417E+1 dBm
2021/12/16 9:57:04.971 1.6421E+1 dBm
2021/12/16 9:57:03.917 1.6415E+1 dBm
2021/12/16 9:57:02.868 1.6416E+1 dBm
2021/12/16 9:57:01.817 1.6420E+1 dBm
2021/12/16 9:57:00.770 1.6421E+1 dBm
2021/12/16 9:56:59.718 1.6415E+1 dBm
2021/12/16 9:56:58.668 1.6413E+1 dBm
2021/12/16 9:56:57.618 1.6414E+1 dBm
2021/12/16 9:56:56.571 1.6412E+1 dBm
2021/12/16 9:56:55.518 1.6412E+1 dBm
2021/12/16 9:56:54.468 1.6416E+1 dBm
2021/12/16 9:56:53.419 1.6417E+1 dBm
2021/12/16 9:56:52.371 1.6417E+1 dBm
2021/12/16 9:56:51.319 1.6417E+1 dBm
2021/12/16 9:56:50.269 1.6416E+1 dBm
2021/12/16 9:56:49.219 1.6412E+1 dBm
2021/12/16 9:56:48.171 1.6412E+1 dBm
2021/12/16 9:56:47.118 1.6415E+1 dBm
2021/12/16 9:56:46.069 1.6416E+1 dBm
2021/12/16 9:56:45.018 1.6416E+1 dBm
2021/12/16 9:56:43.971 1.6414E+1 dBm
2021/12/16 9:56:42.918 1.6417E+1 dBm
2021/12/16 9:56:41.869 1.6415E+1 dBm
2021/12/16 9:56:40.818 1.6415E+1 dBm
2021/12/16 9:56:39.771 1.6418E+1 dBm
2021/12/16 9:56:38.719 1.6417E+1 dBm
2021/12/16 9:56:37.669 1.6416E+1 dBm
2021/12/16 9:56:36.618 1.6418E+1 dBm
2021/12/16 9:56:35.572 1.6417E+1 dBm
2021/12/16 9:56:34.519 1.6416E+1 dBm
2021/12/16 9:56:33.469 1.6410E+1 dBm
2021/12/16 9:56:32.419 1.6410E+1 dBm
2021/12/16 9:56:31.372 1.6412E+1 dBm
2021/12/16 9:56:30.318 1.6412E+1 dBm
2021/12/16 9:56:29.269 1.6410E+1 dBm
2021/12/16 9:56:28.219 1.6409E+1 dBm
2021/12/16 9:56:27.171 1.6416E+1 dBm
2021/12/16 9:56:26.119 1.6416E+1 dBm
2021/12/16 9:56:25.070 1.6416E+1 dBm
2021/12/16 9:56:24.021 1.6415E+1 dBm
2021/12/16 9:56:22.972 1.6423E+1 dBm
2021/12/16 9:56:21.886 1.6415E+1 dBm
KR.CivilLaser.com으로 이동하여 1064nm 단일 모드 파이버 레이저의 안정성 테스트 데이터에 대한 자세한 정보를 찾으십시오.
